Shenzhen Factory wholesale 36w Power adaptor 12v 3a power adapter for CCTV camera

FOB Reference Price:Get Latest Price
$3.15 - $4.60 / Pieces | 1000 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
HRCPOWER
Model Number:
KT36W
Output Type:
DC
Connection:
Plug In
Name:
12v 3a power adapter
Type:
horizonal
Color:
White Black Customized
Output voltage:
12V
Output current:
3000mA
Wattage:
36w Power adaptor
Warranty:
2 YEARS
Certificate:
CE GS UL KC VI CB CCC RoSH
Input:
90~264Vac
working temperature:
0~40℃
Supply Ability
Supply Ability:
100000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
white box ,color box,depent on client requirment
Port
shenzhen
Lead Time :
1-4 working days for sample; 1-4weeks for bulk order
Video Description
Product Description

Shenzhen Factory wholesale 36w Power adaptor 12v 3a power adapter for CCTV camera

* Universal Input Range 90~264VAC
* Meets EN55022 Class B and CISPR/FCC Class B
* Continuous Short Circuit Protection
* Over Voltage Protection
* Meet CEC & ErP Level VI

Typical Model List
OUTPUT VOLTAGE
OUTPUT CURRENT
RIPPLE & NOISE (NOTE 2)
VOLTAGE ACCURACY (NOTE 1)
LINE REGULATION (NOTE 3)
LOAD REGULATION (NOTE 4)
MAX OUTPUT POWER
9.0-12.0V
3000mA
150mV
±5%
±1%
±5%
36.0W
12.1-19.0V
2970mA
150mV
±5%
±1%
±5%
36.0W
19.1-32.0V
18800mA
150mV
±5%
±1%
±5%
36.0W
32.1-48.0V
1120mA
150mV
±5%
±1%
±5%
36.0W
Specification



INPUT :
Voltage:
90~264Vac
Frequency :
 47 to 63Hz

Input Current :
1.0A max.
Inrush Current :
































Cold Start @25℃ 60A max. @240Vac
Leakage Current :
 0.25mA max.


OUTPUT :
Hold-up Time :
Continuous(Auto Recovery)
Short Circuit Protection :
Continuous(Auto Recovery)
Over Voltage Protection :
Yes
Temperature Coefficient :
±0.05%/℃





GENERAL :
Hi-pot :
Input to output = 3.000VAC
Operating Temperature :
0 ~ 40℃
Storage Temperature :
 -20 ~ 80℃
Humidity :
85% RH max. Non condensing
Cooling :
Natural Convection
Switching Frequency :
50KHz Typical MTBF ….MIL-HDBK-217F, GB, at 25℃/115VAC….50Khrs min.
Altitude :
5000m

SAFETY AND EMC :
Emission and lmmunity :
EN55022 Class B, FCC Part 15 Class B EN61000-6-3,EN61000-3-2,EN61000-3-3, EN55024
Safety :
IEC60950, EN60950, UL60950, IEC60065, EN60065, IEC61558, EN61558
NOTE:
1. Voltage accuracy at 60% full load.
2. Add a 0.1uF ceramic capacitor and a 10uF E.L. capacitor to output for Ripple & Noise measurement @20MHz BW.
3. Line regulation is measured from 100V to 240Vac full load.
4. Load regulation is measured from 60% to 100% full load and from 60% to 20% full load (60% +/- 40% full load)

Mechanical Specification
Detail Images
Application
Package and Shipment
Related Prodcuts

US Wall Plug Horizontal Adapter

(12W/24W Series)

EU Wall Plug Vertical Apapter

(12W/24W/36W Series)


UK Wall Plug Vertical Apapter

(12W/24W/36W Series)

Wall Plug Interchangeable Apapter

(48W/56W/60W/65w Series)

US Wall Plug Vertical Apapter

(48W/56W/60W/65w Series)

EU Wall Plug Vertical Apapter

(48W/56W/60W/65w Series)

C6 Desktop Adapter

(60W/90W/120W/200w Series)

C8 Desktop Adapter

(60W/90W/120W/200w Series)

C14 Desktop Adapter

(60W/90W/120W/200w Series)

Company Information


About HRC power

Shenzhen HRCpower Technology Co., Ltd. was founded in 2010 , which is an OEM and ODM manufacturer of power adapter, power supply, battery charger, among other electronic components.

We aim to make high quality, energy-efficient power adapter, which are fully compliant with UL, Fcc, CE, TUV, CB, PSE, CCC, BSMI, GS and SAA. All products will be produced by 500 skillful employees and be designed by 4 R&D teams. We keep updating and improving our products to ensure that we will be your first choice.

For better serve our international customer, we set up Hongkong HRCpower Technology Co., Ltd. in 2013.

Most of our customers are located in the United States, Canada, United Kingdom, Germany, Spain, Australia, Brazil, South Africa, Singapore and Korea, and we seek to establish a long-term business relationships with our customers all over the world.

Exhibition

Customers

Our Service

FAQ (Why choose us ?)

Q: Are you factory?
A :Yes,we are factory specialized in the adapters , R & D production and sales integration ,Price advantage!

Q: How about Warranty?
A : We offer 2 years warranty for our products, Quality is very important for long term business, that's what we do; Product 100% aging test, 100% automatic test instrument detection.

Q:How can I Secure my payment?
A: For Sample,you can pay by Paypal,alibaba trade assurance ; For mass production, alibaba trade assurance ,T/T ,L/C is available, The agreement between each other

 Q: What is shipping method?
A: It depends on your requirement, all available, such as DHL/UPS/FedEX, TNT, special line, Air Cargo, Sea Cargo, Post, etc. We'll try our best to help you save money;

Q: Sample cycle?
A: Sample is available, normally it takes 3~8 work days to prepare, and shipping samples to your country takes 3~7days by DHL

Q: How to work with us? And delivery?
A: We are very sincere to do business with you, normally, after order confirmed and deposit paid, mass production will be arranged within 1-4 weeks; we'll keep you posted about status of production.
