High frequency intelligent charger 3KW 36V 48V 60V 72V 96V AC/DC battery

FOB Reference Price:Get Latest Price
$200.00 - $350.00 / Sets | 10 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
HRCpower
Model Number:
HRC-HF900CH58V8-10
Output Power:
>500W
Output Type:
Single
Input Voltage:
100~240Vac
Output Voltage:
58.8Vdc
Output Frequency:
47-63Hz
Output Current:
8-10a
Certificate:
CB, KC,TUV-MARK,cTUVus,CE,FCC,ROHS
Product Name:
AC/DC battery
Usage:
Electronic Products
Warranty:
2years
LOAD CURRENT(Range):
8.33A
POWER RANGE:
580W
HOLD-UP TIME:
10ms/230VAC
LINE REGULATION:
±1%
LOAD REGULATION:
±1%
WORKING TEMPERATURE:
capacitors up to 105 ℃
Supply Ability
Supply Ability:
100000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
kraft box or depend on client requirement
Port
shenzhen/HK
Lead Time :
1-4 working days for sample order; 1-4 weeks for bulk order
Product Description

High frequency intelligent charger 3KW 36V 48V 60V 72V 96V AC/DC battery

Power supply UGP-HF900CH58V8-10 is cooled by 70*70*25mm 12VDC ball-bearing fans forced air, can work normally under 58.8Vdc/10A, Reverse Protection.ly

Main product specification
Max. output power
Input voltage
Output voltage
Output current
882W
100~240Vac
58.8Vdc
10A
Environmental condition
No.
Item
Technical specification
Unit
Remark
1
Humidity
5%-95%

With package
2
Altitude
≦3000
m
Work normally
3
Cooling
Natural convection cooling

Working under full load
Electrical characteristics
1
Input characteristics
No.
Item
Technical specification
Unit
Remark
1.1
Rated input voltage
100 ~ 240
Vac

1.2
Input voltage range
90 ~ 264
Vac
1.3
AC input voltage frequency
47—63
Hz
1.4
Inrush current
≤100
A
264Vac input/start-up in cold condition /environmental temperature is 25℃
1.5
Max input current
12
A
Vin=90Vac, rated load
1.6
PF
0.95

230Vac@full load
2
Output characteristics
No.
Item
Technical requirements
Unit
Remark

2.1
Deep charge voltage
42
V
Fast charge voltage
58.8
V
2.2
Constant current
10
A
2.3
Output voltage accuracy
±1%

2.4
Power efficiency
≥90%

Vin=100Vac,rated load
3
Protection characteristics
No.
Item
Technical requirements
Remark
3.1
Output over voltage protection
61.6
V
Lockout
3.2
Software over voltage protection
The charger software limits the maximum output voltage to a level suitable for the connected battery system
3.3
Thermal cutback
An internal temperature monitor reduce charger output power in extreme operational temperature to prevent damage
3.4
Output current limiting protection
10
A
@CC MODE
3.5
Output short circuit protection
Short circuit protection should be automatically recovery after remove the condition
3.6
Electronic reverse battery protection
The charger is electronically protected against permanent reverse battery connection
3.7
Cell short circuit timer
Internal software protection
4
Status LED
No.
Item
Status LED
Remark
1
Blue flash
Charging in progress
2
Gree on
Fully charged
3
Red flash
Charge Error
4
Off
NO AC input
5.
Safety & EMC
No.
Item
Standard(or testing condition) Remark
Remark


1


Electric strength test
Input—output
1500Vac/10mA/1min
No breakdown
Input—ground
1500Vac/10mA/1min
Output—ground
500VDC/10mA/ 1min


2


Isolation resistance
Input—output
≥10MΩ@500Vdc
Input—ground
≥10MΩ@500Vdc
Output—ground
≥10MΩ@500Vdc
3
Leakage current
<3.5mA
Vin=264Vac,50—60Hz
4
SAFETY
TUV CE IEC60601-1 EN60601-1






5






EMC
RE
CLASS B
EN55014
CE
CLASS B
EN55014
Air discharge
LEVEL 3
EN61000-4-2(discrimination B)
Contact discharge
LEVEL 3
EN61000-4-2(discrimination B)
RS
LEVEL 3
EN61000-4-6(discrimination A)
CS
LEVEL 3
EN61000-4-3(discriminationA)
EFT
LEVEL 3
EN61000-4-4 (discrimination B)
Surge
LEVEL 3
EN61000-4-5, differentcial module1KV, common module 2KV(discriminationB)
Remark: discrimination A— function OK under technical requirement range; discrimination B--function temporarily debasement without reposition and halt is allowed; discrimination R-- physical damage or failure of equipment are not allowed, but damage of protection device (fuse) caused by interference signal of outside is allowed, and the whole equipment can work normally after replacement of protection device and reset of running parameter.
6.
Environmental testing requirements
No.
Item
Technical specification
Remark
1
High temperature ambient operating
+40℃
Features ok
2
Low temperature ambient operating
-10℃
Features ok
3
High temperature storage
+70℃
Work normally after recovery under normal temperature for two hours
4
Low temperature storage
-40℃
Work normally after recovery under normal temperature for two hours
5
Random Vibration
20Hz to 2000Hz 3Grms 20hours per axis
6
Repetitive Shock
40g peak 3 orthogonal axes,3+ and 3- in each axis ,11ms Pulse width
7
Thermal shock:
-35℃ to +75℃,<3minute transition,2.5hour dwell,200cycle
8
Drop test:
BS EN60068-2-32:1993 Test Ed:Free fall,appendix B
